impression X5 – Product Data

Manual Files: files/products/impression-x5-product-data/GLP_impression_X5_Safety_Manual_EN_Rev_20231011-01.pdffiles/products/impression-x5-product-data/GLP_impression_X5_User_Manual_EN_Rev_20240207-01.pdf
DMX Charts: files/products/impression-x5-product-data/GLP_impression_X5_DMX_Channel_Index_EN_Rev_20240424-01.pdf
Photometric Files: files/products/impression-x5-product-data/GLP_impression_X5_Photometrics_Rev20221019-01.zip
Fixture Lib. Files: files/products/impression-x5-product-data/GLP_impression_X5_MA2_Rev20240618-1.zip
CAD Files: files/products/impression-x5-product-data/GLP_impression_X5_CAD_Rev20240202-1.zipfiles/products/impression-x5-product-data/GLP_impression_X5_Vectroworks_2018-2023_Rev20221201-1.zipfiles/products/impression-x5-product-data/GLP_impression_X5_CAD_Egg_Crate_Rev20220614-1.zipfiles/products/impression-x5-product-data/GLP_impression_X5_CAD_Omega_Bracket_with_Handle_Rev20220614-1.zipfiles/products/impression-x5-product-data/GLP_impression_X5_CAD_Soft_Diffusor_Rev20220614-1.zip
Info Material Files: files/products/impression-x5-product-data/Flyer_X5_digi_Rev20230901.pdffiles/products/impression-x5-product-data/GLP_impression-X5.pdffiles/products/impression-x5-product-data/impression-X5_datasheet_Rev20241010.pdf
Header Image:
Product Picture Gallery:
Tender Text Files: files/products/impression-x5-product-data/GLP_impression_X5_Tendertext_EN_DE_Rev_20250313-1.zip
Product info:
- Long product text (editor):
  The GLP impression X5 is the next generation of high performance, professional LED washlights. Building on the legacy of its highly renowned predecessors, it incorporates cutting edge technology with extensive user input.

  The 19 powerful and exclusive 40 Watt LEDs provide enormous power and allow the fixture to penetrate through even the most difficult lighting environments.

  The light source at the heart of the impression X5 was developed specifically to offer an expanded and more comprehensive color gamut. Incorporating a brand new algorithm, called iQ.Gamut, the impression X5 is able to deliver accuracy, quality and consistency on every occasion. White points are calibrated perfectly to the black body line and the expanded gamut can be accessed via three different color control modes, depending on user preference. Beyond standard mixing, a virtual color wheel is included with 64 referenced LEE color filters.

  Each LED source in the impression X5 can be individually controlled for full pixel mapping effects and a comprehensive effects section is included that has twin layers and many dynamic pattern macros.

  Using the new iQ.Gamut algorithm, the impression X5 creates perfectly calibrated white spectrum outputs with CRI 90 at 6,500 Kelvin and the ability to select other fixed white points down to 3,200 Kelvin, maintaining a high CRI of 85+. Color temperature changes to the output – whether in white or color – can be achieved through a separate, dedicated channel. Further settings for comprehensive control are standard and include Magenta/Green-Shift and a Tungsten Simulation mode with 2x5 settings for different simulations.

  With new super-fast zoom mechanics, the impression X5 offers a staggering 1:16 range running from a punchy 3.5° to 63° with homogenous light distribution across its entire range and without visible hotspots.

  A new front face with a circular design has been conceived to include geometric patterns for great looking effects without any effort.

  Featuring GLP’s trademark Baseless Design, the impression X5 weighs just 13.3 kg / 29.3 lbs, and since it is able to rig in any orientation with the X5 Bracket, the impression X5 looks elegant in any environment. The impression X5 has been designed for use in live concerts, television, film and broadcast, theatre and musicals, live events, exhibitions, music festivals, houses of worship and other application settings, and can easily be mounted into set pieces.

  Built-in accessory mountings on the front of the impression X5 allow users to easily add front accessories such as top hats or honeycomb shields.

  16-bit movement, with speeds that go from silent to breakneck speed, the impression X5 runs through 540°/650° of Pan and 220° of Tilt with full feedback control.

  The impression X5 can be controlled via DMX, ArtNet or sACN and has an integrated Near Field Control Sensor for setup and adjustments from a smart device. Also onboard is a GLP iQ.Service Module, compatible with the GLP iQ.Service App, and the new GLP FPO (Flexible Protocol Option) Port for alternative control protocol options.

  Additional features include: variable PWM settings, auto ranging power input, multiple performance modes, failsafe ethernet connectors and much more.

  With its meticulous attention to detail, output and control, and with the inclusion of extensive knowledge and market input, the impression X5 truly represents a breakthrough in the professional LED washlight market.
  , Short product description: 19 powerful RGBL LED's for stunning Color rendering
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In, Neutrik etherCON port A & B (failsafe)
Aufbau:
- Daten enthalten?: Aufbau, Eigenschaften: gebaut für externes Zubehör (Egg Crate, Tubus, etc.) | Tilt-Lock-System | baseless Design | GLP FX.Port, Gehäusefarbe: schwarz, Gehäusematerial: schlagfestes flammhemmendes Thermoplastik, Aluminium, Stahlblech, Schutzklasse: IP20
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: M1: Basic | M2: Normal | M3: Segment | M4: Multipix Advanced | M5: Multipix Compressed RGB | M6: Multipix Compressed RGBL, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX (FPO), Art-Net, sACN, GLP iQ.Mesh, DMX Channels: M1: 24 | M2: 35 | M3: 41 | M4: 89 | M5: 70 | M6: 89, Dimmerkurven: linear, soft, S-Curve, Fan Modes: regulated, high, medium, low, High-Res Channels: Pan | Tilt | Intensity | Colormix, Weitere Steuerungsoptionen: Art-Net/sACN Node | Data Conversion | NFC | FPO Port (Flexible Protocol Option), PWM: Low | Optimal | High 1 | High 2, Performance Modes: Fast, Normal (Balanced), Smooth, Einstellung und Adressierung: beleuchtetes Grafik-LCD, 4 Button Menu Navigation, DMX, RDM, iQ.Service App, 1 Scene Stand Alone, Geräte-Update: DMX Link via Dprog, GLP iQ.Mesh, Subfixture Mode: normal, independent, Weißpunkte: 6.500 K (Standard) | 8.000 K | 5.600 K | 4.200 K | 3.200 K
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 290 mm / 11.4 in, Höhe: 402 – 434 mm / 15.83 – 17.09 in, Gewicht (netto): 13,3 kg / 29.3 lbs, Breite (Arm zu Arm): 415 mm / 16.4 in, Mindestabstand Mitte zu Mitte: 465 mm / 18.3 in
Dynamische Effekte:
- Daten enthalten?: Dynamische Effekte, Farbmischung: RGB, RGBL, x;y, Color Mix Priority: verschiedene Einstellungen für Layer Priority, Farbrad: virtual, 64 LEE referenced colors, rainbow, CQC: High Output (HO), High Quality (HQ), Desaturation, CTC: variabel 2.500 – 10.000 K, Dimmer / Shutter: 0 – 100%, 16 bit, Strobe, Pulse, Sparkel, etc., Magenta/Grün-Korrektur: vorhanden, Pattern Effekte: 50 dynamische Pattern Macros mit Spezialeffekten, Tungsten Simulation: 8x verknüpft mit festem CCT | 8x relativ zu Colormix, Zoom speed: super fast zoom mechanics
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 710 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CRI: 8.000 K: 87 | 6.500 K: 86+ | 3.200 K: 84+, Anzahl: 19, Duv: perfekte Weißpunkt-Treffer mit niedrigen Duv Werten, LED Refresh Rate: Low: 550 Hz, Optimal: dynamic PWM Algorithm, High 1: 4.600 Hz, High 2: 13.000 Hz, alle Werte gerundet; für genauere Informationen GLP Support kontaktieren, Lebensdauer: 50.000 h, TLCI: 8.000 K: 90 | 6.500 K: 88+ | 3.200 K: 74+, TM-30-15: 6.500 K: 87/105 | 3.200 K: 85/110, Typ: RGBL
Installation:
- Daten enthalten?: Installation, Standort: indoor, Befestigung: 1 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, M10 Gewinde, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,1 m, Mindestabstand zu beleuchteten Oberflächen: 1,0 m
Bewegung:
- Daten enthalten?: Bewegung, Pan Angle: 540° normal (650° erweitert), 16 bit, Tilt Angle: 240°, 16 bit
Optisches System:
- Daten enthalten?: Optisches System, Frontlinse: 19 Linsen mit runder Öffnung, Durchmesser 260 mm, max. Zoom: 63°, min. Zoom: 3,5°, Maximale Lichtintensität: 2 Mcd, Licht-Output: bis zu 12.500 lm, Zoomverhältnis: 1:16
Light Source:
- Data Category: Light Source, CRI: 8,000 K: 87 | 6,500 K: 86+ | 3,200 K: 84+, CT: 6,500 K, Count: 19, Duv: perfect white point matches with low Duv values, LED Refresh Rate: Low: 550 Hz, Optimal: dynamic PWM Algorithm, High 1: 4,600 Hz, High 2: 13,000 Hz, all values rounded; for detailed information, contact GLP Supprt, Lifetime: 50,000 h, Power: 40 W, TLCI: 8,000 K: 90 | 6,500 K: 88+ | 3,200 K: 74+, TM-30-15: 6,500 K: 87/105 | 3,200 K: 85/110, Type: RGBL
Dynamic Effects:
- Data Category: Dynamic Effects, Color Mixing: RGB, RGBL, x;y, Color Mix Priority: different Layer Priority settings, Color wheel: virtual, 64 LEE referenced colors, rainbow, CQC: High Output (HO), High Quality (HQ), Desaturation, CTC: variable 2,500 – 10,000 K, Dimmer / Shutter: 0 – 100%, 16 bit, Strobe, Pulse, Sparkel, etc., Magenta/Green-Correction: Yes, Pattern Effects: 50 dynamic pattern macros with special effects, Tungsten Simulation: 8x linked to fix CCT | 8x relative to Colormix, Zoom speed: super fast zoom mechanics
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: Kombination aus Konvektions- und Zwangskühlung, Überhitzungsschutz: automatisch, Gesamtwärmeabgabe: 2.500 BTU/hr, max. Umgebungstemperatur: 45 °C / 115 °F, min. Umgebungstemperatur: 5 °C / 40 °F
Connections:
- Data Category: Connections, Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out, Neutrik etherCON port A & B (failsafe)
Construction:
- Data Category: Construction, Construction features: prepared for external accessories (Egg Crate, Tubus, etc.) | Tilt-Lock-System | baseless design | GLP FX.Port, Housing color: Black, Housing material: high-impact flame-retardand thermoplastic, aluminum, steel metal plates, Protection Rating: IP20
Movement:
- Data Category: Movement, Pan Angle: 540° normal (650° extended), 16 bit, Tilt Angle: 240°, 16 bit
Electrical Specifications:
- Data Category: Electrical Specifications, Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 710 W
Installation:
- Data Category: Installation, Location: Indoor, Mounting: 1 pair of 1/4-turn locks, 2 eyelets for safety cable, M10 thread, Orientation: any, min. distance to combustible materials: 0.1 m, min. distance to illuminated surfaces: 1.0 m
Dimensions & Weight:
- Data Category: Dimensions & Weight, Depth: 290 mm / 11.4 in, Height: 402 – 434 mm / 15.83 – 17.09 in, Weight (netto): 13.3 kg / 29.3 lbs, Width (across yoke): 415 mm / 16.4 in, min. center-to-center-distance: 465 mm / 18.3 in
Optical System:
- Data Category: Optical System, Front lens: 19 lenses with full circular aperature, diameter 260 mm, max. Zoom: 63°, min. Zoom: 3.5°, Peak Luminous Intensity: 2 Mcd, Total Output: up to 12,500 lm, Zoom ratio: 1:16
Control & Programming:
- Data Category: Control & Programming, Control Modes: M1: Basic | M2: Normal | M3: Segment | M4: Multipix Advanced | M5: Multipix Compressed RGB | M6: Multipix Compressed RGBL, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX (FPO), Art-Net, sACN, GLP iQ.Mesh, DMX Channels: M1: 24 | M2: 35 | M3: 41 | M4: 89 | M5: 70 | M6: 89, Dimming curves: linear, soft, S-Curve, Fan Modes: regulated, high, medium, low, High-Res Channels: Pan | Tilt | Intensity | Colormix, Other control options: Art-Net/sACN Node | Data Conversion | NFC | FPO Port (Flexible Protocol Option), PWM: Low | Optimal | High 1 | High 2, Performance Modes: Fast, Normal (Balanced), Smooth, Setting and addressing: backlit graphic LCD, 4 Button Menu Navigation, DMX, RDM, iQ.Service App, GLP iQ.Mesh, 1 Scene Stand Alone, Software update: DMX Link via Dprog, GLP iQ.Mesh, Subfixture Mode: normal, independent, White Points: Default: 6,500 K | optional: 8,000 K | 5,600 K | 4,200 K | 3,200 K
Thermal Specifications:
- Data Category: Thermal Specifications, Cooling Type: combined convection and forced air, Overheating protection: automatic, Total heat dissipation: 2,500 BTU/hr, max. ambient temperature: 45 °C / 115 °F, min. ambient temperature: 5 °C / 40 °F

Hits: 1032

Written by Elisabeth Riemesch on 27 June 2023. Posted in PD Event Lighting.

impression X5 IP Maxx – Product Data

Manual Files: files/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_Maxx_Safety_Manual_EN_Rev20241007-1.pdffiles/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_MAXX_User_Manual_EN_Rev20250119-01.pdf
DMX Charts: files/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_MAXX_DMX_Channel_Index_Rev20240711-01.pdf
Photometric Files: files/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_MAXX_Photometrics_Rev_20230119-1.zip
Fixture Lib. Files: files/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_MAXX_MA2_Rev20240919-1.zip
CAD Files: files/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_MAXX_CAD_Rev_20241104-1.zipfiles/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_Maxx_Vectorworks_Rev20240703-1.zip
Info Material Files: files/products/impression-x5-ip-maxx-product-data/impression-X5-IP-Maxx_Datasheet_Rev20250430.pdf
Header Image:
Product Picture Gallery:

impression X5 IP Maxx

impression X5 IP Maxx

impression X5 IP Maxx

impression X5 IP Maxx
Tender Text Files: files/products/impression-x5-ip-maxx-product-data/GLP_impression_X5_IP_MAXX_Tendertext_EN_DE_Rev_20250313-1.zip
Product info:
- Long product text (editor):
  The GLP impression X5 IP Maxx delivers an extraordinary luminous flux of up to 21,000 lumens, with an expanded colour space, from 37 powerful 40-watt RGBL LEDs.

  Equipped with the new iQ.Gamut colour algorithm, the impression X5 IP Maxx generates a clean white point with a CRI 86 / TLCI 88+ at 6,500 Kelvin. It also offers the option of quickly switching to other fixed colour temperatures, all of which are precisely calibrated to the colour temperature curve, while still offering a colour quality of CRI 84+ / TLCI 74 even with warm white light of 3,200 Kelvin.

  With the new 19:1 zoom mechanism, the impression X5 IP Maxx delivers up to 3.56 Mcd light intensity, a penetrating 3.3° parallel beam and up to 66° homogeneous wash light. The new, circular lens design offers a modern look, while additional fantastic looks can be generated using individual pixel control with pixel mapping and integrated dynamic pattern effects.

  The impression X5 IP Maxx comes with an extensive feature and effects package, including a virtual colour wheel with access to 64 colours from the LEE filter palette, new colour quality control, magenta/green correction, a tungsten simulation and effects channel and a 2-layer effect option.

  Thanks to the IP65 certification, the fixture can be used both indoors and outdoors in any weather. The compact design, with a weight of < 30 kg, is designed for easily installation in standard pre-rig truss systems.

  The impression X5 IP Maxx can be controlled via DMX, ArtNet, sACN and LumenRadio CRMX. It also has NFC and the iQ.Mesh module for convenient configuration via the GLP iQ.Service app.
  , Short product description: 37 powerful RGBL LED's for stunning Color rendering, IP65 certified
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out, Neutrik etherCON port A & B (failsafe)
Aufbau:
- Daten enthalten?: Aufbau, Eigenschaften: vorbereitet für externes Zubehör | Tilt-Lock-System, Gehäusefarbe: schwarz, Gehäusematerial: schlagfestes flammhemmendes Thermoplastik, Aluminium, Stahlblech, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: M1: Basic | M2: Normal | M3: Segment | M4: Multipix Advanced | M5: Multipix Compressed RGB | M6: Multipix Compressed RGBL, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX (FPO), Art-Net, sACN, GLP iQ.Mesh, DMX Channels: M1: 22 | M2: 33 | M3: 42 | M4: 141 | M5: 122 | M6: 159, Dimmerkurven: linear, soft, S-Curve, Fan Modes: regulated, high, medium, minimum, High-Res Channels: Pan | Tilt | Intensity | Colormix, Weitere Steuerungsoptionen: Art-Net/sACN Node | Data Conversion | FPO Port (Flexible Protocol Option), PWM: Low | Optimal | High 1 | High 2, Performance Modes: Fast, Normal (Balanced), Smooth, Einstellung und Adressierung: beleuchtetes Grafik-LCD, 4 Button Menu Navigation, DMX, RDM, iQ.Service App, GLP iQ.Mesh, NFC über iQ.Service App, 1 Scene Stand Alone, Geräte-Update: DMX Link via Dprog, GLP iQ.Mesh, Subfixture Mode: normal, independent, Weißpunkte: 8.000 K | 5.600 K | 4.200 K | 3.200 K
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 358 mm / 14.1 in, Höhe: 631 mm / 24.8 in, Gewicht (netto): 29,7 kg / 65.5 lbs, Breite (Arm zu Arm): 483 mm / 19 in
Dynamische Effekte:
- Daten enthalten?: Dynamische Effekte, Farbmischung: RGB, RGBL, x;y, Color Mix Priority: verschiedene Einstellungen für Layer Priority, Farbrad: virtuell, 64 LEE referenzierte Farben, CQC: High Output (HO), High Quality (HQ), Desaturation, CTC: variabel 2.500 – 10.000 K, Dimmer / Shutter: 0 – 100%, 16 bit, Strobe, Pulse, Sparkel, etc., Magenta/Grün-Korrektur: vorhanden, Pattern Effekte: 50 dynamische Pattern Macros mit Spezialeffekten, Tungsten Simulation: 8x verknüpft mit festem CCT | 8x relativ zu Colormix, Zoom speed: extrem schnelle Zoom-Mechanik
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 1.500 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CRI: 8,000 K: 87 | 6,500 K: 86+ | 3,200 K: 84+, CT: 6.500 K, Anzahl: 37, Duv: perfekte Weißpunkt-Treffer mit niedrigen Duv Werten, LED Refresh Rate: Low: 550 Hz, Optimal: dynamic PWM Algorithm, High 1: 4.600 Hz, High 2: 13.000 Hz, alle Werte gerundet; für genauere Informationen GLP Support kontaktieren, Lebensdauer: 50.000 h, TLCI: 8,000 K: 90 | 6,500 K: 88+ | 3,200 K: 74, TM-30-15: 6.500 K: 87/105 | 3.200 K: 85/110, Typ: RGBL LED
Installation:
- Daten enthalten?: Installation, Standort: indoor, outdoor, Befestigung: 2 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, 2x M10 Gewinde, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,1 m, Mindestabstand zu beleuchteten Oberflächen: 1,0 m
Bewegung:
- Daten enthalten?: Bewegung, Pan Angle: 540° normal (650° erweitert), 16 bit, Tilt Angle: 240°, 16 bit
Optisches System:
- Daten enthalten?: Optisches System, Frontlinse: 37 Linsen mit runder Öffnung, Durchmesser 380 mm, max. Zoom: 66°, min. Zoom: 3,3°, Maximale Lichtintensität: 3,56 Mcd, Licht-Output: bis zu 21.000 lm, Zoomverhältnis: 1:19
Light Source:
- Data Category: Light Source, CRI: 8,000 K: 87 | 6,500 K: 86+ | 3,200 K: 84+, CT: 6,500 K, Count: 37, Duv: perfect white point matches with low Duv values, LED Refresh Rate: Low: 550 Hz, Optimal: dynamic PWM Algorithm, High 1: 4,600 Hz, High 2: 13,000 Hz, all values rounded; for detailed information, contact GLP Supprt, Lifetime: 50,000 h, Power: 40 W, TLCI: 8,000 K: 90 | 6,500 K: 88+ | 3,200 K: 74, TM-30-15: 6,500 K: 87/105 | 3,200 K: 85/110, Type: RGBL LED
Lieferung:
- Daten enthalten?: Lieferung, Tourpack: 2-fach, Flightcase, Omega Brackets
Dynamic Effects:
- Data Category: Dynamic Effects, Color Mixing: RGB, RGBL, x;y, Color Mix Priority: different Layer Priority settings, Color wheel: virtual, 64 LEE referenced colors, rainbow, CQC: High Output (HO), High Quality (HQ), Desaturation, CTC: variable 2,500 – 10,000 K, Dimmer / Shutter: 0 – 100%, 16 bit, Strobe, Pulse, Sparkel, etc., Magenta/Green-Correction: Yes, Pattern Effects: 50 dynamic pattern macros with special effects, Tungsten Simulation: 8x linked to fix CCT | 8x relative to Colormix, Zoom speed: super fast zoom mechanics
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: Kombination aus Konvektions- und Zwangskühlung, Überhitzungsschutz: automatisch, Gesamtwärmeabgabe: 5.120 BTU/hr, max. Umgebungstemperatur: 45 °C / 115 °F, min. Umgebungstemperatur: -10 °C / 14 °F
Connections:
- Data Category: Connections, Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out, Neutrik etherCON port A & B (failsafe)
Construction:
- Data Category: Construction, Construction features: prepared for external accessories | Tilt-Lock-System, Housing color: Black, Housing material: high-impact flame-retardand thermoplastic, aluminum, steel metal plates, Protection Rating: IP65
Movement:
- Data Category: Movement, Pan Angle: 540° normal (650° extended), 16 bit, Tilt Angle: 240°, 16 bit
Electrical Specifications:
- Data Category: Electrical Specifications, Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 1,500 W
Installation:
- Data Category: Installation, Location: Indoor, Outdoor, Mounting: 2 pairs of 1/4-turn locks, 2 eyelets for safety cable, 2x M10 threads, Orientation: any, min. distance to combustible materials: 0.1 m, min. distance to illuminated surfaces: 1.0 m
Shipping:
- Data Category: Shipping, Tourpack: 2-way, Flightcase, Omega Brackets
Dimensions & Weight:
- Data Category: Dimensions & Weight, Depth: 358 mm / 14.1 in, Height: 631 mm / 24.8 in, Weight (netto): 29.7 kg / 65.5 lbs, Width (across yoke): 483 mm / 19 in
Optical System:
- Data Category: Optical System, Front lens: 37 lenses with full circular aperature, diameter 380 mm / 14.9 in, max. Zoom: 66°, min. Zoom: 3.3°, Peak Luminous Intensity: 3.56 Mcd, Total Output: up to 21,000 lm, Zoom ratio: 1:19
Control & Programming:
- Data Category: Control & Programming, Control Modes: M1: Basic | M2: Normal | M3: Segment | M4: Multipix Advanced | M5: Multipix Compressed RGB | M6: Multipix Compressed RGBL, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX (FPO), Art-Net, sACN, GLP iQ.Mesh, DMX Channels: M1: 22 | M2: 33 | M3: 42 | M4: 141 | M5: 122 | M6: 159, Dimming curves: linear, soft, S-Curve, Fan Modes: regulated, high, medium, minimum, High-Res Channels: Pan | Tilt | Intensity | Colormix, Other control options: Art-Net/sACN Node | Data Conversion | FPO Port (Flexible Protocol Option), PWM: Low | Optimal | High 1 | High 2, Performance Modes: Fast, Normal (Balanced), Smooth, Setting and addressing: backlit graphic LCD, 4 Button Menu Navigation, DMX, RDM, iQ.Service App, GLP iQ.Mesh, NFC via iQ.Service App, 1 Scene Stand Alone, Software update: DMX Link via Dprog, GLP iQ.Mesh, Subfixture Mode: normal, independent, White Points: optional: 8,000 K | 5,600 K | 4,200 K | 3,200 K
Thermal Specifications:
- Data Category: Thermal Specifications, Cooling Type: combined convection and forced air, Overheating protection: automatic, Total heat dissipation: 5,120 BTU/hr, max. ambient temperature: 45 °C / 115 °F, min. ambient temperature: -10 °C / 14 °F

ES und FR sind nicht aktuell!

Hits: 346

Written by Elisabeth Riemesch on 26 June 2023. Posted in PD Event Lighting.

GT-1 FL – Product Data

Manual Files: files/products/gt-1-fl-product-data/GT-1_User_Manual_EN_Rev.B_20190215.pdf
DMX Charts: files/products/gt-1-fl-product-data/GT1_DMX_Channel_Index_EN_r5.pdf
Photometric Files: files/products/gt-1-fl-product-data/GT-1_Photometric.zip
CAD Files: files/products/gt-1-fl-product-data/GT-1_CAD_-_3D.zipfiles/products/gt-1-fl-product-data/GT-1_Dimensions.pdffiles/products/gt-1-fl-product-data/GT-1_Vectorworks.zipfiles/products/gt-1-fl-product-data/GT-1_WYSIWYG.zip
Info Material Files: files/products/gt-1-fl-product-data/GLP_GT-1_Cut_Sheet_EN.pdffiles/products/gt-1-fl-product-data/GT-1_Data_Sheet_EN.pdf
Header Image:
Product Picture Gallery:

GT-1 FL

GT-1 FL
Product info:
- Long product text (editor):
  The GT-1 FL from GLP is a true hybrid fixture, working as both a Spot and a Beam fixture with highest levels of performance. Using a high powered 470 Watt discharge lamp, its high quality optical system produces a light beam that features an enormous 22:1 ratio zoom range from 3.5° to 56.7°.

  When in spot mode, the GT-1 FL offers a wide range of effects, including CMY color mixing, eight rotating gobos, 14 fixed pattern gobos, additional beam reduction gobos, and an interchangeable animation wheel. But it doesn’t stop there, the GT-1 also features three different rotating prisms, a fixed color wheel with CTO/CTB filters, and a frost for softening the beam.

  When in beam mode, the GT-1 FL produces an astonishing highly parallel beam of light at 2.5° through its large 145mm diameter front lens, that remains bright and consistent over long distances.

  The GLP GT-1 FL features our unique baseless design, wireless DMX control (optional), full 16 bit pan and tilt movement, full range dimming and shuttering capability, an in built battery for fixture setup, an auto sensing power supply and a low weight of just 25kg, in all giving a vastly versatile fixture for a wide range of applications.
  , Short product description: The ultimate Hybrid Fixture
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 3-Pin In/Out, Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Gehäusefarbe: schwarz, Sonderfarben auf Anfrage
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: Normal, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), Einstellung und Adressierung: beleuchtetes Grafik-LCD, intuitive TouchWheel Steuerung, selbstaufladende Pufferbatterie
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe (Kopf gerade hoch): 229 mm / 9 in, Höhe (Kopf gerade hoch): 618 mm / 24.3 in, Gewicht (netto): 25 kg / 55 lbs, Breite (Arm zu Arm): 472 mm / 18.6 in
Dynamische Effekte:
- Daten enthalten?: Dynamische Effekte, Farbmischung: CMY, Farbrad: 11 dichroitische Farbfilter, CTB Filter, CTO Filter, CTC: 2.500 K – 9.000 K, mechanisch, Dimmer / Shutter: 0 – 100%, elektromechanisch, Effektrad: rotier- und indexierbar, austauschbar, Frost: vorhanden, Prisma: 3-fach, 4-fach, 8-fach, drehbar
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Sicherung: T8A 20mm, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, max. Leistung (@ 230 V): 720 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CT: 7.300 K, Lebensdauer: 1.500 h, Typ: Entladungslampe
Installation:
- Daten enthalten?: Installation, Befestigung: 2 Ösen für Sicherungskabel, 4x Camlock und 2x M10 Gewinde, M10 Gewinde, Omega Bracket, einstellbare Schiene für seitliche Trussmontage (optional), abnehmbarer Standfuß mit Ösen für Ratschgurte, Ausrichtung: beliebig
Bewegung:
- Daten enthalten?: Bewegung, Pan Angle: 537° (standard), 637° (erweitert), 8 – 16 bit, Tilt Angle: 270°, 8 – 16 bit
Optisches System:
- Daten enthalten?: Optisches System, Fokus: 2 m – unendlich, motorisiert, max. Zoom: 56,7°, min. Zoom: 3,5°, Zoomverhältnis: 1:22
Light Source:
- CT: 7,300 K, Lifetime: 1,500 h, Type: Discharge lamp
Lieferung:
- Daten enthalten?: Lieferung, einzelnes Gerät: Karton, Tourpack: 2-fach, Flightcase, Omega Brackets
Dynamic Effects:
- Color Mixing: CMY, Color wheel: 11 dichroic filters, CTB Filter, CTO Filter, CTC: 2,500 K – 9,000 K, mechanical, Dimmer / Shutter: 0 – 100%, electromechanical, Effect wheel: rotatable and indexable, interchangeable, Frost: yes, Gobo wheel: 8 Gobos, rotatable and indexable, changable, Dicro color gobos, Gobo wheel 2: 14 fix metal gobos plus 6 different pinholes, Prism: 3-way, 4-way, 8-way, rotatable
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Überhitzungsschutz: automatisch, max. Umgebungstemperatur: 45 °C / 115 °F
Connections:
- Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 3-Pin In/Out, Neutrik XLR 5-Pin In/Out
Construction:
- Housing color: Black, special colors on request
Movement:
- Pan Angle: 537° (default), 637° (extended), 8 – 16 bit, Tilt Angle: 270°, 8 – 16 bit
Electrical Specifications:
- Fuse: T8A 20mm, Power Input: 100 – 240 VAC / 50 – 60 Hz, max. Power (@ 230 V): 720 W
Installation:
- Mounting: 2 eyelets for safety cable, 4x Camlock and 2x M10 threads, M10 thread, Omega Bracket, adjustable rail for sideways truss installation (optional), removable baseplate with brackets for ratchet belt, Orientation: any
Shipping:
- single fixture: carton, Tourpack: 2-way, Flightcase, Omega Brackets
Dimensions & Weight:
- Depth (head straight up): 229 mm / 9 in, Height (head straight up): 618 mm / 24.3 in, Weight (netto): 25 kg / 55 lbs, Width (across yoke): 472 mm / 18.6 in
Optical System:
- Focus: 2 m – infinity, motorized, max. Zoom: 56.7°, min. Zoom: 3.5°, Zoom ratio: 1:22
Control & Programming:
- Control Modes: Normal, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), Setting and addressing: backlit graphic LCD, intuitive touch wheel control, self charging buffer battery
Thermal Specifications:
- Overheating protection: automatic, max. ambient temperature: 45 °C / 115 °F

Hits: 743

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION Stick FS20 – Product Data

Manual Files: files/products/fusion-stick-fs20-product-data/Manual_Fusion_Stick_FS20.pdf
Fixture Lib. Files: files/products/fusion-stick-fs20-product-data/FS20_Fixture_MA.zipfiles/products/fusion-stick-fs20-product-data/GLP_FUSION_Stick_FS20_Camsys_Rev20210715-1.zip
CAD Files: files/products/fusion-stick-fs20-product-data/DWG_DXF_3_copy_1.zip
Info Material Files: files/products/fusion-stick-fs20-product-data/FUSION_Stick-FS20FS10_EN.pdffiles/products/fusion-stick-fs20-product-data/GLP-Installation_FUSION-Stick-FS20_DE.pdffiles/products/fusion-stick-fs20-product-data/GLP-Installation_FUSION-Stick-FS20_EN.pdf
Header Image:
Product Picture Gallery:

FUSION Stick FS20

FUSION Stick FS20

FUSION Stick FS20
Tender Text Files: files/products/fusion-stick-fs20-product-data/FUSION-FS20_tender-text-GER.zip
Firmware: files/products/fusion-stick-fs20-product-data/FS20_V1034_20220218.zip
Product info:
- Long product text (editor):
  The FUSION Stick FS20 has the ability to easily add various beam angle filters, including asymmetrical options, producing a perfectly homogeneous light output. The Stick features 20°, 40°, 60° and 60°x10° diffuser plates which can be fixed to the front of the fixture. With these diffuser plates attached the Stick outputs enough power to produce light beams that cut through modern stage designs.

  As with all FUSION by GLP fixtures the FUSION Stick FS20 fixtures feature an IP rating of 65, allowing for full outdoor use regardless of poor weather conditions. To that end the Stick features a fanless design, which not only ensures an IP65 rating, but also enables silent operation for sound sensitive environments such as theaters or television.

  The Stick fixtures feature FUSION’s SteadyColor™ technology which allows color mixing through the RGBW LED’s to remain exact through all dimming levels removing the possibility of color shifts and the need for single color correction.

  Additionally the Stick fixtures feature the uniquely designed ConsistentColor™ optic which creates the perfect balance of output and homogeneity, producing high quality light output without coronas or color shifts.

  No matter what the application the FUSION Stick FS20 is the right choice.
  , Short product description: 20 x 15 Watt RGBW Osram® LEDs, 6° ConsistentColor™ Optic, fanless outdoor design
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Eigenschaften: Alignment System | austauschbarer Frontscreen, Gehäusefarbe: schwarz, Gehäusematerial: Aluminium, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 8, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX DMX/RDM (optional), Einstellung und Adressierung: OLED Display mit 4 Knöpfen, DMX, RDM, Geräte-Update: DMX Link via Updater
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 90 mm / 3.54 in, Höhe: 231 mm / 9.09 in, Gewicht (netto): 12,5 kg / 27.55 lbs, Breite: 1.019 mm / 40.12 in
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 357 W, max. Anzahl Geräte auf einer Stromleitung: 4 @ 100 – 120 V, 60 Hz | 10 @ 200 – 240 V, 50 Hz
Lichtquelle:
- Daten enthalten?: Lichtquelle, Anzahl: 20, Lebensdauer: 20.000 h, Leistung: 15 W, Typ: RGBW
Installation:
- Daten enthalten?: Installation, Standort: outdoor, Befestigung: 2 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,5 m, Mindestabstand zu beleuchteten Oberflächen: 0,5 m
Optisches System:
- Daten enthalten?: Optisches System, max. beam angle: 6° half peak
Light Source:
- Count: 20, Lifetime: 20,000 h, Power: 15 W, Type: RGBW
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: lüfterlose Konvektionskühlung, Überhitzungsschutz: automatisch, max. Umgebungstemperatur: 45 °C / 113 °F, min. Umgebungstemperatur: -10 °C / 14 °F
Connections:
- Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Construction features: Alignment System | Changeable Frontscreen, Housing color: Black, Housing material: aluminum, Protection Rating: IP65
Electrical Specifications:
- Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 357 W, max. number of products per current line: 4 @ 100 – 120 V, 60 Hz | 10 @ 200 – 240 V, 50 Hz
Installation:
- Location: Outdoor, Mounting: 2 pairs of 1/4-turn locks, 2 eyelets for safety cable, Orientation: any, min. distance to combustible materials: 0.5 m, min. distance to illuminated surfaces: 0.5 m
Dimensions & Weight:
- Depth: 90 mm / 3.54 in, Height: 231 mm / 9.09 in, Weight (netto): 12.5 kg / 27.55 lbs, Width: 1,019 mm / 40.12 in
Optical System:
- min. beam angle: 6° half peak
Control & Programming:
- Control Modes: 8, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX DMX/RDM (optional), Setting and addressing: OLED Display with 4 buttons, DMX, RDM, Software update: DMX Link via Updater
Thermal Specifications:
- Cooling Type: convection, Overheating protection: automatic, max. ambient temperature: 45 °C / 113 °F, min. ambient temperature: -10 °C / 14 °F

Hits: 1788

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION Stick FS16 Z – Product Data

Manual Files: files/products/fusion-stick-fs16-z-product-data/GLP_Fusion_FS16Z_User_Manual_EN_Rev_20240625-01.pdf
DMX Charts: files/products/fusion-stick-fs16-z-product-data/GLP_Fusion_FS16Z_DMX_Channel_Index_EN_Rev_20240625-01.pdf
Photometric Files: files/products/fusion-stick-fs16-z-product-data/GLP_FUSION_Stick_FS16_Z_Photometrics_Rev20210715-1.zip
Fixture Lib. Files: files/products/fusion-stick-fs16-z-product-data/GLP_Fusion_Stick_FS16Z_MA2_Rev_20240412-1.zip
CAD Files: files/products/fusion-stick-fs16-z-product-data/GLP_FUSION_FS16Z_CAD_Rev_20241111-1.zip
Info Material Files: files/products/fusion-stick-fs16-z-product-data/GLP_FUSION_Stick_FS16_Z_Cut_Sheet.pdffiles/products/fusion-stick-fs16-z-product-data/GLP_FUSION_Stick_FS16_Z_Datasheet.pdf
Header Image:
Product Picture Gallery:

FUSION Stick FS16 Z

FUSION Stick FS16 Z

FUSION Stick FS16 Z

FUSION Stick FS16 Z
Tender Text Files: files/products/fusion-stick-fs16-z-product-data/GLP_FUSION_Stick_FS16_Z_tender-text-GER.zip
Product info:
- Long product text (editor):
  The FUSION Stick FS16 Z has a motorized zoom between 10° and 41° beam angle. It is still the same size and dimensions as the FUSION Stick FS20, so all diffusors, including asymmetrical options, and accessories are available to use.

  The Halo Ring is another innovation implemented to increase pixel visibility in TV applications. In all camera angles the single pixels are visible at any zoom position due to the ring around the front lens and still create stunning narrow beams.

  The FUSION Stick FS16 Z features an IP rating of 65, allowing for full outdoor use regardless of poor weather conditions. To that end the Stick features a fanless design, which not only ensures the IP65 rating, but also enables silent operation for sound sensitive environments such as theaters or television.

  The direct vertical hanging and standing are one of the key features to create stunning effects with less rigging effort.

  No matter the application, the FUSION Stick FS16 Z is the right choice.
  , Short product description: IP65, fanless, 8 to 40 degrees Zoom, Halo Ring for improved pixel visibility
Zulassungen & Klassifizierungen:
- Daten enthalten?: Zulassungen & Klassifizierungen, Risk Group EN 62471: Risk Group 2
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Eigenschaften: austauschbarer Frontscreen | IR Sensor für Fernbedienung | vertikale Anbringung, Gehäusefarbe: schwarz, Gehäusematerial: Aluminium, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 4, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 4 | 14 | 33 | 79, High-Res Channels: Dimmer, Weitere Steuerungsoptionen: 3 Layer Pattern-FX-Engine, Einstellung und Adressierung: 4 Button Menu Navigation, DMX, RDM, IR Sensor für Fernbedienung, Geräte-Update: DMX Link via Updater
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 90 mm / 3.5 in, Höhe: 236 mm / 9.3 in, Gewicht (netto): 13 kg / 18.66 lbs, Breite: 1.023 mm / 40.6 in
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 450 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CRI: 70+, CT: 6.000 K, Anzahl: 16, Lebensdauer: 20.000 h, Leistung: 20 W, TLCI: 42, TM-30-15: 97 / 62, Typ: RGBW
Installation:
- Daten enthalten?: Installation, Standort: outdoor, Befestigung: 2 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,5 m, Mindestabstand zu beleuchteten Oberflächen: 0,5 m
Optisches System:
- Daten enthalten?: Optisches System, max. Zoom: 41°, min. Zoom: 10°, Licht-Output: bis zu 5.890 lm, Zoomverhältnis: 1:4
Light Source:
- CRI: 70+, CT: 6,000 K, Count: 16, Lifetime: 20,000 h, Power: 20 W, TLCI: 42, TM-30-15: 97 / 62, Type: RGBW
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: lüfterlose Konvektionskühlung, Überhitzungsschutz: automatisch, Gesamtwärmeabgabe: 1.535 BTU/hr, max. Umgebungstemperatur: 40 °C / 104 °F, min. Umgebungstemperatur: -10 °C / 14 °F
Connections:
- Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Construction features: Changeable Front screen | IR Sensor for Remote Control | direct vertical hanging, Housing color: Black, Housing material: aluminum, Protection Rating: IP65
Electrical Specifications:
- Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 450 W
Installation:
- Location: Outdoor, Mounting: 2 pairs of 1/4-turn locks, 2 eyelets for safety cable, Orientation: any, min. distance to combustible materials: 0.5 m, min. distance to illuminated surfaces: 0.5 m
Dimensions & Weight:
- Depth: 90 mm / 3.5 in, Height: 236 mm / 9.3 in, Weight (netto): 13 kg / 18.66 lbs, Width: 1,023 mm / 40.6 in
Optical System:
- max. Zoom: 41°, min. Zoom: 10°, Total Output: up to 5,890 lm, Zoom ratio: 1:4
Control & Programming:
- Control Modes: 4, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 4 | 14 | 33 | 79, Other control options: 3 Layer Pattern-FX-Engine, Setting and addressing: 4 Button Menu Navigation, DMX, RDM, IR Sensor for Remote Control, Software update: DMX Link via Updater
Thermal Specifications:
- Cooling Type: convection, Overheating protection: automatic, Total heat dissipation: 1,535 BTU/hr, max. ambient temperature: 40 °C / 104 °F, min. ambient temperature: -10 °C / 14 °F
Approvals & Classifications:
- Risk Group EN 62471: Risk Group 2

Hits: 655

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION Stick FS10 – Product Data

DMX Charts: files/products/fusion-stick-fs10-product-data/FUSION_Stick_FS10_DMX_Channel_Index_EN_Rev_A_FINAL.pdf
Photometric Files: files/products/fusion-stick-fs10-product-data/FUSION_FS10_Photometrics_Rev20210715-1.zip
Fixture Lib. Files: files/products/fusion-stick-fs10-product-data/FS10_Fixture_MA.zip
CAD Files: files/products/fusion-stick-fs10-product-data/2019_Stick_FS10.zipfiles/products/fusion-stick-fs10-product-data/FS10_CAD.zip
Info Material Files: files/products/fusion-stick-fs10-product-data/FUSION_STICK_FS20FS10_Cut_Sheet_EN.pdffiles/products/fusion-stick-fs10-product-data/GLP_Installation_FUSION_Stick_FS10_DE.pdffiles/products/fusion-stick-fs10-product-data/GLP_Installation_FUSION_Stick_FS10_EN.pdf
Header Image:
Product Picture Gallery:

FUSION Stick FS10

FUSION Stick FS10

FUSION Stick FS10
Tender Text Files: files/products/fusion-stick-fs10-product-data/FUSION-FS10_tender-text-GER.zip
Firmware: files/products/fusion-stick-fs10-product-data/FS10_V1034_20220218.zip
Product info:
- Long product text (editor):
  The FUSION Stick FS10 has the ability to easily add various beam angle filters, including asymmetrical options, producing a perfectly homogeneous light output. The Stick features 20°, 40°, 60° and 60°x10° diffuser plates which can be fixed to the front of the fixture. With these diffuser plates attached the Stick outputs enough power to produce light beams that cut through modern stage designs.

  As with all FUSION by GLP fixtures the FUSION Stick FS10 fixtures feature an IP rating of 65, allowing for full outdoor use regardless of poor weather conditions. To that end the Stick features a fanless design, which not only ensures an IP65 rating, but also enables silent operation for sound sensitive environments such as theaters or television.

  The Stick fixtures feature FUSION’s SteadyColor™ technology which allows color mixing through the RGBW LED’s to remain exact through all dimming levels removing the possibility of color shifts and the need for single color correction.

  Additionally the Stick fixtures feature the uniquely designed ConsistentColor™ optic which creates the perfect balance of output and homogeneity, producing high quality light output without coronas or color shifts.

  No matter what the application the FUSION Stick FS10 is the right choice.
  , Short product description: 10 x 15 Watt RGBW Osram® LEDs, 6° ConsistentColor™ Optic, fanless outdoor design
Zulassungen & Klassifizierungen:
- Daten enthalten?: Zulassungen & Klassifizierungen, Risk Group EN 62471: Risk Group 2
Batterie Spezifikationen:
- Daten enthalten?: Batteriespezifikationen
Anschlüsse:
- Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Eigenschaften: Alignment System | austauschbarer Frontscreen, Gehäusefarbe: schwarz, Gehäusematerial: Aluminium, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 8, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX DMX/RDM (optional), Einstellung und Adressierung: OLED Display mit 4 Knöpfen, DMX, RDM, Geräte-Update: DMX Link via Updater
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 90 mm / 3.54 in, Höhe: 231 mm / 9.09 in, Gewicht (netto): 7,5 kg / 16.54 lbs, Breite: 525 mm / 20.67 in
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, max. Leistung (@ 230 V): 179 W, max. Anzahl Geräte auf einer Stromleitung: 9 @ 100 – 120 V, 60 Hz | 20 @ 200 – 240 V, 50 Hz
Lichtquelle:
- Daten enthalten?: Lichtquelle, Anzahl: 10, Lebensdauer: 20.000 h, Leistung: 15 W, Typ: RGBW
Installation:
- Daten enthalten?: Installation, Standort: outdoor, Befestigung: 2 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,5 m, Mindestabstand zu beleuchteten Oberflächen: 0,5 m
Optisches System:
- Daten enthalten?: Optisches System, min. beam angle: 6° half peak
Light Source:
- Count: 10, Lifetime: 20,000 h, Power: 15 W, Type: RGBW
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: lüfterlose Konvektionskühlung, Überhitzungsschutz: automatisch, max. Umgebungstemperatur: 45 °C / 113 °F, min. Umgebungstemperatur: -10 °C / 14 °F
Connections:
- Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Construction features: Alignment System | Changeable Frontscreen, Housing color: Black, Housing material: aluminum, Protection Rating: IP65
Electrical Specifications:
- Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 179 W, max. number of products per current line: 9 @ 100 – 120 V, 60 Hz | 20 @ 200 – 240 V, 50 Hz
Installation:
- Mounting: 2 pairs of 1/4-turn locks, 2 eyelets for safety cable, Orientation: any, min. distance to combustible materials: 0.5 m, min. distance to illuminated surfaces: 0.5 m
Dimensions & Weight:
- Depth: 90 mm / 3.54 in, Height: 231 mm / 9.09 in, Weight (netto): 7.5 kg / 16.54 lbs, Width: 525 mm / 20.67 in
Optical System:
- min. beam angle: 6° half peak
Control & Programming:
- Control Modes: 8, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), LumenRadio CRMX DMX/RDM (optional), Setting and addressing: OLED Display with 4 buttons, DMX, RDM, Software update: DMX Link via Updater
Thermal Specifications:
- Cooling Type: convection, Overheating protection: automatic, max. ambient temperature: 45 °C / 113 °F, min. ambient temperature: -10 °C / 14 °F
Approvals & Classifications:
- Risk Group EN 62471: Risk Group 2

Hits: 556

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION PAR FP7 – Product Data

Manual Files: files/products/fusion-par-fp7-product-data/FP7_Control_Menus_EN_Rev_A.pdf
DMX Charts: files/products/fusion-par-fp7-product-data/FP7_DMX_Channel_Index_EN_Rev_A.pdf
Fixture Lib. Files: files/products/fusion-par-fp7-product-data/glpfusion_par_fp7modes.zip
CAD Files: files/products/fusion-par-fp7-product-data/FP7_CAD.zip
Info Material Files: files/products/fusion-par-fp7-product-data/FUSION_PAR_FP7_Cut_Sheet_EN.pdf
Header Image:
Product Picture Gallery:

FUSION PAR FP7

FUSION PAR FP7

FUSION PAR FP7
Product info:
- Long product text (editor):
  The FUSION PAR FP7 is equipped with seven high power 30 Watt RGBW LEDs by Osram®. This fixture is build for outdoor applications and is IP65 certified. There are also 20°, 40° and 60° diffusor plates available which can be fixed easliy at the front.
  , Short product description: 7 x 30 Watt RGBW Osram® LEDs, IP65 classification, powerCON TRUE1 / 5pol DMX, very compact housing
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Gehäusefarbe: schwarz, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 6, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 2 | 3 | 4 | 5 | 6 | 8, Einstellung und Adressierung: OLED Display mit 4 Knöpfen, DMX, RDM
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe (Kopf gerade hoch): 237 mm / 9.33 in, Höhe (Kopf gerade hoch): 287 mm / 11.29 in, Gewicht (netto): 7,7 kg / 16.97 lbs, Breite (Arm zu Arm): 166 mm / 6.53 in
Dynamische Effekte:
- Daten enthalten?: Dynamische Effekte, Farbmischung: RGBW, Farbrad: virtuell, 39 Farben inklusive Weißtöne, Dimmer / Shutter: 0 – 100%, elektronisch, Strobe-Effekte
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 222 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, Anzahl: 7, Lebensdauer: 20.000 h, Leistung: 30 W, Typ: RGBW
Installation:
- Daten enthalten?: Installation, Befestigung: 1 Öse für Sicherungskabel
Optisches System:
- Daten enthalten?: Optisches System, max. beam angle: 6°
Light Source:
- Count: 7, Lifetime: 20,000 h, Power: 30 W, Type: RGBW
Dynamic Effects:
- Color Mixing: RGBW, Color wheel: virtual, 39 colors inclusive whites, Dimmer / Shutter: 0 – 100%, electronical, selectable dimming curves, Strobe effects
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Gesamtwärmeabgabe: 758 BTU/h, max. Umgebungstemperatur: 45 °C / 113 °F
Connections:
- Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Housing color: Black, Protection Rating: IP65
Electrical Specifications:
- Power Input: 100 – 240 VAC / 50 – 60 Hz, max. Power (@ 230 V): 222 W
Installation:
- Mounting: 1 eyelet for safety cable
Dimensions & Weight:
- Depth (head straight up): 237 mm / 9.33 in, Height (head straight up): 287 mm / 11.29 in, Weight (netto): 7.7 kg / 16.97 lbs, Width (across yoke): 166 mm / 6.53 in
Optical System:
- max. beam angle: 6°
Control & Programming:
- Control Modes: 6, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 2 | 3 | 4 | 5 | 6 | 8, Setting and addressing: OLED Display with 4 buttons, DMX, RDM
Thermal Specifications:
- Total heat dissipation: 758 BTU/h, max. ambient temperature: 45 °C / 113 °F

Hits: 825

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION MBL 40 – Product Data

Manual Files: files/products/fusion-mbl-40-product-data/FUSION_MBL_40_User_Manual_EN_Rev_A_FINAL.pdf
Photometric Files: files/products/fusion-mbl-40-product-data/FUSION_MBL_40_Photometrics_Rev_20230505-1.zip
Fixture Lib. Files: files/products/fusion-mbl-40-product-data/fusion-mbl-20_40modes.zip
CAD Files: files/products/fusion-mbl-40-product-data/FUSION_MBL_40_CAD.zip
Info Material Files: files/products/fusion-mbl-40-product-data/FUSION_MBL_20__40_Cut_Sheet_EN.pdffiles/products/fusion-mbl-40-product-data/FUSION_MBL_20__40_Data_Sheet_EN.pdffiles/products/fusion-mbl-40-product-data/GLP_Installation_FUSION_MBL_DE.pdffiles/products/fusion-mbl-40-product-data/GLP_Installation_FUSION_MBL_EN.pdf
Header Image:
Product Picture Gallery:

FUSION MBL 40

FUSION MBL 40

FUSION MBL 40
Tender Text Files: files/products/fusion-mbl-40-product-data/Tenderspecs_FUSION_MBL_40.zip
Product info:
- Long product text (editor):
  The MBL 40 is a tunable white floodlight with an adjustable color temperature range from 2,700 to 6,500 Kelvin. Due to the fanless concept the MBL 40 is the ideal general light for fairs, events, sports or show areas or in all sound sensitive areas. The MBL 40 is classified according to IP65, therefore dustproof and also suitable for outdoor use. The integrated diffuser improves the lighting properties of the LED by reducing glare and providing a homogeneous visual impression.

  Highlights are the direct selector switches for color temperature and brightness, which can be used to set the most important color temperatures and fixed brightness levels without current; ideal for simple Plug&Play applications. For the integration in installations the MBL 40 supports DMX 512 and can be controlled individually. For the use in the video/TV sector selectable PWM frequencies (up to 30 KHz) are at hand. The MBL 40 has In/Out connections for DMX and power (Neutrik powerCON TRUE1) which makes the installation and dismantling very easy.

  Optional accessories such as hinged doors for an extended optical protection (glare shield) and to limit the light are available at product launch.
  , Short product description: IP65 classified tunable white floodlight, color temperature range from 2,700 to 6,500 Kelvin, fanless
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Gehäusefarbe: schwarz, Gehäusematerial: Aluminium, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 2, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 2 | 5, Fan Modes: regulated, high, medium, low, High-Res Channels: Linear | Square Law | Inv. Square | Theater, Performance Modes: Fast, Normal (Balanced), Smooth, Einstellung und Adressierung: 4 Button Menu Navigation, DMX, RDM, Geräte-Update: DMX Link via Updater
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 217 mm / 8.54 in, Höhe: 380 mm / 14.96 in, Gewicht (netto): 10 kg / 22 lbs, Breite: 320 mm / 12.6 in, Breite (Arm zu Arm): 482 mm / 18.98 in
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 400 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CRI: 80+, Anzahl: 55x cW, 55x wW, Lebensdauer: 50.000 h, Leistung: 5 W, TM-30-15: 80+ / 90+, Typ: cW/wW LED
Installation:
- Daten enthalten?: Installation, Standort: outdoor, Befestigung: 1 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,5 m, Mindestabstand zu beleuchteten Oberflächen: 0,5 m
Optisches System:
- Daten enthalten?: Optisches System, max. beam angle: 100°
Light Source:
- Data Category: Light Source, CRI: 80+, Count: 55x cW, 55x wW, Lifetime: 50,000 h, Power: 5 W, TM-30-15: 80+ / 90+, Type: cW/wW LED
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: Kombination aus Konvektions- und Zwangskühlung, Überhitzungsschutz: automatisch, Gesamtwärmeabgabe: 682 BTU/hr, max. Umgebungstemperatur: 45 °C / 115 °F, min. Umgebungstemperatur: -10 °C / 14 °F
Connections:
- Data Category: Connections, Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Data Category: Construction, Housing color: Black, Housing material: aluminum, Protection Rating: IP65
Electrical Specifications:
- Data Category: Electrical Specifications, Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 400 W
Installation:
- Data Category: Installation, Location: Outdoor, Mounting: 1 pair of 1/4-turn locks, 2 eyelets for safety cable, Orientation: any, min. distance to combustible materials: 0.5 m, min. distance to illuminated surfaces: 0.5 m
Dimensions & Weight:
- Data Category: Dimensions & Weight, Depth: 217 mm / 8.54 in, Height: 380 mm / 14.96 in, Weight (netto): 10 kg / 22 lbs, Width: 320 mm / 12.6 in, Width (across yoke): 482 mm / 18.98 in
Optical System:
- Data Category: Optical System, max. beam angle: 100°
Control & Programming:
- Data Category: Control & Programming, Control Modes: 2, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 2 | 5, Fan Modes: regulated, high, medium, low, High-Res Channels: Linear | Square Law | Inv. Square | Theater, Performance Modes: Fast, Normal (Balanced), Smooth, Setting and addressing: 4 Button Menu Navigation, DMX, RDM, Software update: DMX Link via Updater
Thermal Specifications:
- Data Category: Thermal Specifications, Cooling Type: combined convection and forced air, Overheating protection: automatic, Total heat dissipation: 682 BTU/hr, max. ambient temperature: 45 °C / 115 °F, min. ambient temperature: -10 °C / 14 °F

Hits: 908

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION MBL 20 – Product Data

Manual Files: files/products/fusion-mbl-20-product-data/FUSION_MBL_20_User_Manual_EN_Rev_A_FINAL.pdf
Photometric Files: files/products/fusion-mbl-20-product-data/FUSION_MBL_20_Photometrics_Rev_20230505-1.zip
Fixture Lib. Files: files/products/fusion-mbl-20-product-data/fusion-mbl-20_40modes.zip
CAD Files: files/products/fusion-mbl-20-product-data/FUSION_MBL_20_CAD.zip
Info Material Files: files/products/fusion-mbl-20-product-data/FUSION_MBL_20__40_Cut_Sheet_EN.pdffiles/products/fusion-mbl-20-product-data/FUSION_MBL_20__40_Data_Sheet_EN.pdffiles/products/fusion-mbl-20-product-data/GLP_Installation_FUSION_MBL_DE.pdffiles/products/fusion-mbl-20-product-data/GLP_Installation_FUSION_MBL_EN.pdf
Header Image:
Product Picture Gallery:

FUSION MBL 20

FUSION MBL 20

FUSION MBL 20
Tender Text Files: files/products/fusion-mbl-20-product-data/Tenderspecs_FUSION_MBL_20.zip
Product info:
- Long product text (editor):
  The MBL 20 is a tunable white floodlight with an adjustable color temperature range from 2,700 to 6,500 Kelvin. Due to the fanless concept the MBL 20 is the ideal general light for fairs, events, sports or show areas or in all sound sensitive areas. The MBL 20 is classified according to IP65, therefore dustproof and also suitable for outdoor use. The integrated diffuser improves the lighting properties of the LED by reducing glare and providing a homogeneous visual impression.

  Highlights are the direct selector switches for color temperature and brightness, which can be used to set the most important color temperatures and fixed brightness levels without current; ideal for simple Plug&Play applications. For the integration in installations the MBL 20 supports DMX 512 and can be controlled individually. For the use in the video/TV sector selectable PWM frequencies (up to 30 KHz) are at hand. The MBL 20 has In/Out connections for DMX and power (Neutrik powerCON TRUE1) which makes the installation and dismantling very easy.

  Optional accessories such as hinged doors for an extended optical protection (glare shield) and to limit the light are available at product launch.
  , Short product description: IP65 classified tunable white floodlight, color temperature range from 2,700 to 6,500 Kelvin, fanless
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Gehäusefarbe: schwarz, Gehäusematerial: Aluminium, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 2, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 2 | 5, Fan Modes: regulated, high, medium, low, High-Res Channels: Linear | Square Law | Inv. Square | Theater, Performance Modes: Fast, Normal (Balanced), Smooth, Einstellung und Adressierung: 4 Button Menu Navigation, DMX, RDM, Geräte-Update: DMX Link via Updater
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe: 170 mm / 6.69 in, Höhe: 270 mm / 10.63 in, Gewicht (netto): 5 kg / 11 lbs, Breite: 250 mm / 9.84 in, Breite (Arm zu Arm): 370 mm / 14.57 in
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 200 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CRI: 80+, Anzahl: 27x cW, 27x wW, Lebensdauer: 50.000 h, Leistung: 5 W, TM-30-15: 80+ / 90+, Typ: cW/wW LED
Installation:
- Daten enthalten?: Installation, Standort: outdoor, Befestigung: 1 Paar 1/4-Drehverschlüsse, 2 Ösen für Sicherungskabel, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,5 m, Mindestabstand zu beleuchteten Oberflächen: 0,5 m
Optisches System:
- Daten enthalten?: Optisches System, max. beam angle: 100°
Light Source:
- Data Category: Light Source, CRI: 80+, Count: 27x cW, 27x wW, Lifetime: 50,000 h, Power: 5 W, TM-30-15: 80+ / 90+, Type: cW/wW LED
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: Kombination aus Konvektions- und Zwangskühlung, Überhitzungsschutz: automatisch, Gesamtwärmeabgabe: 682 BTU/hr, max. Umgebungstemperatur: 45 °C / 115 °F, min. Umgebungstemperatur: -10 °C / 14 °F
Connections:
- Data Category: Connections, Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Data Category: Construction, Housing color: Black, Housing material: aluminum, Protection Rating: IP65
Electrical Specifications:
- Data Category: Electrical Specifications, Power Input: 100 – 240 VAC / 50 – 60 Hz, Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 200 W
Installation:
- Data Category: Installation, Location: Outdoor, Mounting: 1 pair of 1/4-turn locks, 2 eyelets for safety cable, Orientation: any, min. distance to combustible materials: 0.5 m, min. distance to illuminated surfaces: 0.5 m
Dimensions & Weight:
- Data Category: Dimensions & Weight, Depth: 170 mm / 6.69 in, Height: 270 mm / 10.63 in, Weight (netto): 5 kg / 11 lbs, Width: 250 mm / 9.84 in, Width (across yoke): 370 mm / 14.57 in
Optical System:
- Data Category: Optical System, max. beam angle: 100°
Control & Programming:
- Data Category: Control & Programming, Control Modes: 2, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 2 | 5, Fan Modes: regulated, high, medium, low, High-Res Channels: Linear | Square Law | Inv. Square | Theater, Performance Modes: Fast, Normal (Balanced), Smooth, Setting and addressing: 4 Button Menu Navigation, DMX, RDM, Software update: DMX Link via Updater
Thermal Specifications:
- Data Category: Thermal Specifications, Cooling Type: combined convection and forced air, Overheating protection: automatic, Total heat dissipation: 682 BTU/hr, max. ambient temperature: 45 °C / 115 °F, min. ambient temperature: -10 °C / 14 °F

Hits: 411

Written by Elisabeth Riemesch on 23 June 2023. Posted in PD Event Lighting.

FUSION Exo Wash 30 – Product Data

Manual Files: files/products/fusion-exo-wash-30-product-data/EXO_Wash_30_User_Manual_EN_Rev_B.pdf
DMX Charts: files/products/fusion-exo-wash-30-product-data/EXO_Wash_30_DMX_Channel_Index_EN_Rev_A_FINAL.pdf
Photometric Files: files/products/fusion-exo-wash-30-product-data/FUSION_Exo_Wash_30_Photometrics_Rev20210715-1.zip
Fixture Lib. Files: files/products/fusion-exo-wash-30-product-data/EXO_Wash_30_Fixture_Library.zip
CAD Files: files/products/fusion-exo-wash-30-product-data/FUSION_EXO_Wash_30_CAD_Rev20230310-1.zip
Info Material Files: files/products/fusion-exo-wash-30-product-data/FUSION-ExoWash30_datasheet-Rev20250821.pdf
Header Image:
Product Picture Gallery:

FUSION Exo Wash 30

FUSION Exo Wash 30

FUSION Exo Wash 30
Product info:
- Long product text (editor):
  The Exo Wash 30 from FUSION by GLP is an IP65 rated Moving Head wash fixture with a full feature set in a compact housing.

  Featuring a durable and robust die cast housing, the Exo Wash 30 is ready for the toughest of outdoor weather conditions. With 7 powerful 32 W RGBW Osram LEDs, the FUSION Exo Wash 30 delivers a solid, bright beam in a full color range from the deepest saturates to the lightest pastel shades, and offers color control over each individual pixel.

  Supporting the stunning output is a zooming optical system that can vary the beam continuously from 4° to 54°.

  The Exo Wash 30 incorporates True1 In/Out connectors, variable PWM control and also features easy to use magnetic head mounts, for filter holders and any other future attachments.
  , Short product description: IP65 Moving Head Wash Light, 7 powerful 40 Watt RGBW Osram LEDs, wide color range including saturated and pastel shades, single pixel control
Anschlüsse:
- Daten enthalten?: Anschlüsse, Netzanschluss: Neutrik powerCON TRUE1 In/Out, Signalverbindung: Neutrik XLR 5-Pin In/Out
Aufbau:
- Daten enthalten?: Aufbau, Eigenschaften: Pan/Tilt-Lock-System | integrierte Griffe in der Basis, Gehäusefarbe: schwarz, Schutzklasse: IP65
Steuerung & Programmierung:
- Daten enthalten?: Steuerung & Programmierung, Control Modes: 4, Protokolle: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 13 | 22 | 37 | 50, Dimmerkurven: linear, soft, Fan Modes: regulated, high, medium, low, High-Res Channels: Dimmer | Tilt | Pan | R | G | B | W, Einstellung und Adressierung: beleuchtetes Grafik-LCD, 4 Button Menu Navigation, DMX, RDM, Geräte-Update: DMX Link via Updater
Maße & Gewicht:
- Daten enthalten?: Maẞe & Gewicht, Tiefe (Kopf gerade hoch): 279 mm / 11 in, Höhe (Kopf gerade hoch): 521 mm / 20.5 in, Gewicht (netto): 19,7 kg / 43.43 lbs, Breite (Arm zu Arm): 380 mm / 14.96 in
Dynamische Effekte:
- Daten enthalten?: Dynamische Effekte, Farbmischung: RGBW
Elektrische Spezifikationen:
- Daten enthalten?: Elektrische Spezifikationen, Sicherung: T5A 250V 20mm, Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz, Netzteil: Schaltnetzteil, max. Leistung (@ 230 V): 230 W
Lichtquelle:
- Daten enthalten?: Lichtquelle, CRI: 73, Anzahl: 7, Lebensdauer: 20.000 h, Leistung: 40 W, Typ: RGBW LED
Installation:
- Daten enthalten?: Installation, Standort: outdoor, Befestigung: 2 Paar 1/4-Drehverschlüsse, 1 Öse für Sicherungskabel, Ausrichtung: beliebig, Mindestabstand zu entzündlichen Materialien: 0,5 m, Mindestabstand zu beleuchteten Oberflächen: 0,5 m
Bewegung:
- Daten enthalten?: Bewegung, Pan Angle: 540°, 16 bit, Tilt Angle: 267°, 16 bit
Optisches System:
- Daten enthalten?: Optisches System, max. Zoom: 54°, min. Zoom: 4°
Light Source:
- Data Category: Light Source, CRI: 73, Count: 7, Lifetime: 20,000 h, Power: 40 W, Type: RGBW LED
Dynamic Effects:
- Data Category: Dynamic Effects, Color Mixing: RGBW
Thermische Spezifikationen:
- Daten enthalten?: Thermische Spezifikationen, Kühlung: Kombination aus Konvektions- und Zwangskühlung, Überhitzungsschutz: automatisch, Gesamtwärmeabgabe: 785 BTU/hr, max. Umgebungstemperatur: 45 °C / 115 °F, min. Umgebungstemperatur: -20 °C / -4 °F
Connections:
- Data Category: Connections, Power connection: Neutrik powerCON TRUE1 In/Out, Signal connection: Neutrik XLR 5-Pin In/Out
Construction:
- Data Category: Construction, Construction features: Pan/Tilt-Lock-System | integrated base handles, Housing color: Black, Protection Rating: IP65
Movement:
- Data Category: Movement, Pan Angle: 540°, 16 bit, Tilt Angle: 267°, 16 bit
Electrical Specifications:
- Data Category: Electrical Specifications, Fuse: T5A 250V 20mm, Power Input: 100 – 200 VAC / 50 – 60 Hz (at 1,000 W lamp power), Power supply unit: auto-ranging electronic switch-mode, max. Power (@ 230 V): 230 W
Installation:
- Data Category: Installation, Mounting: 2 pairs of 1/4-turn locks, 1 eyelet for safety cable, Orientation: any, min. distance to combustible materials: 0.5 m, min. distance to illuminated surfaces: 0.5 m
Dimensions & Weight:
- Data Category: Dimensions & Weight, Depth (head straight up): 279 mm / 11 in, Height (head straight up): 521 mm / 20.5 in, Weight (netto): 19.7 kg / 43.43 lbs, Width (across head): 380 mm / 14.96 in
Optical System:
- Data Category: Optical System, max. Zoom: 54°, min. Zoom: 4°
Control & Programming:
- Data Category: Control & Programming, Control Modes: 4, Control Protocols: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), DMX Channels: 13 | 22 | 37 | 50, Dimming curves: linear, soft, Fan Modes: regulated, high, medium, low, High-Res Channels: Dimmer | Tilt | Pan | R | G | B | W, Setting and addressing: backlit graphic LCD, 4 Button Menu Navigation, DMX, RDM, Software update: DMX Link via Updater
Thermal Specifications:
- Data Category: Thermal Specifications, Cooling Type: combined convection and forced air, Overheating protection: automatic, Total heat dissipation: 785 BTU/hr, max. ambient temperature: 45 °C / 115 °F, min. ambient temperature: -20 °C / -4 °F

Hits: 1161
